GPS SMS Tracker

Text your location on request.

Overview

A NEO-6M gets position and a SIM800L texts a map link when it receives an SMS. Needs a 2G-capable SIM and a supply that can deliver 2 A peaks.

Wire the GPS
NEO-6M TX/RX to software-serial pins; test outdoors for a first fix.
Power the GSM module
Use an LM2596 set to about 4.0 V for the SIM800L, with common ground.
Reply to SMS
On a request, read the GPS position and send a Google Maps link.

The products for this build. Quantities are suggested starting points — confirm in your quotation.

Female-to-Female Jumper Wires 20 cm (Pack of 40)
Module to module.
Qty 1 (Pack of 40)Recommended
ABS Project Box 150×90×45 mm
Box for UNO builds and relay boards.
Qty 1 (Each)Recommended
12 V 2 A DC Power Supply
Clean 12 V for relays, strips and motors.
Qty 1 (Each)Recommended
LM2596 Adjustable Buck Converter
Step voltage down efficiently.
Qty 1 (Each)Required
SIM800L GSM/GPRS Module
SMS and calls from a microcontroller.
Qty 1 (Each)Required
NEO-6M GPS Module with Antenna
Position, speed and time.
Qty 1 (Each)Required
UNO R3 Development Board
ATmega328P board programmed over USB.
Qty 1 (Each)Required

Adds all 7 products with their suggested quantities. You can edit everything in your quote.
